When the external voltage and resistance is 12 VDC and 1 KΩ respectively, opto-isolated output
electrical feature is as follows.
Note
With different external voltage and resistance, the corresponding current and output logic level
low may have small change.
SC2000 Series Vision Sensor User Manual
Figure 4-3 Internal Circuit of PNP Output Signal
Figure 4-4 Internal Circuit of NPN Output Signal
Figure 4-5 Output Logic Level
8
