In display interface, enable Display Text to set text's color, front size, transparency, position X, and
position Y.

7.5.9 Ethernet/IP

Ethernet/IP is a network communication standard capable of handling large amounts of data at
speeds of 10 Mbps or 100 Mbps, and at up to 1500 bytes per packet. It is an an application layer
protocol, and is especially popular for control applications.
After completing settings in PLC, you can use the Ethernet/IP communication to link the result
data, and run the solution continuously.
In display interface, enable Display Text to set text's color, front size, transparency, position X, and
position Y.

7.6 Solution Completion

The others module, you can set solution name and save solution, set solution running interval and
permission assignment, etc.
In Save Solution, you can enter a solution name.
Note
After creating a new solution, if you do not change the default solution name (Untitled), you
cannot save it.
In Enable Running Items, you can set the solution continuous running interval.
Note
It only takes effect when the Trigger Mode is OFF.
If you have enabled technician permission, you can check All in Permission Assignment to open all
modules to technician, or check specific ones to assign them to technician.
SC2000 Series Vision Sensor User Manual
Figure 7-40 Ethernet/IP
57
