No.
Name
5
Light Source
6
Screw
7
Screw Hole
8
PWR Indicator
9
STS Indicator
10
LNK Indicator
11
Button
SC2000 Series Vision Sensor User Manual
The device has 8 LED lamps providing light, and the light source is
white spotlight by default. You can select wide-angle or spotlight
lamp, and white, red, blue or near-infrared is optional.
It refers to the screw between device body and lens cap.
It is used to fix the device to installation position. You should use
M4 screw.
It is the power indicator. The indicator is green when the device
operates normally. Otherwise, it is red.
It is the status indicator. The indicator is green when the solution
operates normally. Otherwise, it is red.
It is network status indicator. The indicator is flashing green when
the network transmission is normal. Otherwise, it is unlit.
It is used to trigger device solution operation.
Description
3
