SC2000 Series Vision Sensor User Manual
Table 8-3 Icon Description
Icon
Description
Click it to download the image to the PC. The default format is JPG.
Click it to zoom out the displayed image.
It displays the current image-scaling ratio.
Click it to zoom in the displayed image.
Click it to set image size as 1:1.
Figure 8-5 Image Display Area
62
