7.1.6 Set Image

Go to Image to set image related parameters.
Pixel Format
The mono device supports Mono 8 only, and the color device supports Mono 8 and RGB.
Width
It refers to the image width, and you can adjust it according to actual demands.
Height
It refers to the image height, and you can adjust it according to actual demands.
Width Deviation and Height Deviation
It indicates the starting location of the upper left corner of the ROI area, that is, the deviation in
the X direction and Y direction. This parameter adjusts the location of the ROI frame.
Note
Image width + width deviation <= width max. value. Image height + height deviation <= height
max. value.
W-H Conversion
This parameter is 1 by default, and it sets the relation between image coordinates and physical
coordinates, that is, a pixel on the image represents the length in actual physical position.
Gamma
Gamma correction provides a non-linear mapping mechanism. When Gamma value is between
is 0 and 1, image brightness increases, and dark area becomes brighter. When Gamma value is
between 1 and 4, image brightness decreases, and dark area becomes darker.
