Digital trigger commands
You can send specific commands from external systems and devices to trigger various actions. These
digital triggers are very useful for system integration and automation.
This also allows users to incorporate control over the DiGidot C4 in other software programs.
Detailed API information can be found in our DiGidot C4 API document on our website, go to
https://digidot.eu/support/documentation
If you need further API information, please contact us.
OSC
Home > Triggers > select '+' to add a trigger > select 'OSC'
OSC (Open Sound Control) is a protocol that is often being used in audio and video applications in
order to send data over a network. Due to the open and easy to use standard and various low cost
OSC applications to create user interfaces, this protocol is ideal to be used in lighting applications.
There are various third party OSC applications that reported to work in combination with the DiGidot
C4. A few apps that we can recommend are
from ON LX Ltd. Please note that DiGidot does not offer any support for third party apps and
softwares. The DiGidot C4 only supports messages with the float type.
Enable OSC trigger
Before creating OSC triggers, OSC must be enabled first. This can be done by creating an OSC trigger
and press the 'enable' link or do the following steps:
1. Go to:
Home > Triggers > click on the 3 dots in the top right blue bar > select 'HTTP, UDP and OSC'
2. Enable the OSC triggers option and click the 'save' button.
Add an OSC trigger
An OSC trigger can be created in two ways:
1.
Learn an incoming OSC Address
Press the 'LEARN' button and send the Address from an OSC app or software.
Note that the OSC sending application must be connected to the C4 network and the correct
IP address of the recipient must be set.
2.
Enter an OSC Address manually
Enter the same Address that is used by to the OSC app or software.
After saving the OSC trigger it will be listed in the Triggers overview. Use the copy button in the
trigger item to copy the OSC command and paste it to your software program.
Address for OSC editor
C4 Manual
TouchOSC
from hexler.net,
Version 2.2.0
Lemur
from Liine or
Ctrl
42-78
