Play scene

‣ Scene: Select the desired scene from the drop-down menu.
‣ Brightness: Set the brightness for this action.
‣ Fade time: Set the fade for this action.
Layer: Set the layer where the scene needs to be played.
‣

Play playlist

A playlist is a list of scenes with fade times and needs to be created in the main menu item called
"Playlists".
Playlist: Select the desired playlist from the drop-down menu.
‣

Action list

The action list allows multiple actions and sub actions to be triggered in consecutive order, by the
same trigger input, every time this trigger state is positive.
Every step in this list is indicated by a #number and can be ordered with the drag and drop feature.
Every action may contain one or multiple sub actions that are triggered at the same time. An action
list always loops, this means it will start at the first step again if you trigger it at the last step of the
action list.
Select an action from the drop-down menu. An action will add one or more extra options depending
on the action type. E.G., a Scene will add a drop-down menu to select a scene and an option to set a
fade time.
ADD SUBACTION:
All of the action types described in this chapter are available as a subaction as well. This allows
multiple actions to be executed when triggered by the same single. You can also have an action list
with multiple steps. By clicking the "ADD ACTION" an extra step will be created. Each time the input
triggers are 'true' the action list will go the next step in the action list.

Pause

This will pause any scene or playlist that is playing.
Effect: You can add an affect that determines the way a scene is stopped.
No effect (default): This will instantly pause the scene.
Speed transition: This will gradually decrease the speed to 0% within the entered time.
Brightness (fade out) transition: This will gradually decrease the brightness to 0% within the
entered time.
Speed and brightness (fade out) transition: This will gradually decrease the speed and fade
out the brightness to 0% within the entered time.

Resume

Resumes playing any paused scene or playlist.
