Analog dimming: select one of the three analog inputs that will control the overall
‣
brightness of this IO configuration item.
16-bit input: When sending 16-bit data to the DiGidot C4, two input channels are used for
‣
one color channel. If your IC does not support 16 bit and you want to convert 16-bit to 8-
bit, please enable this option. If your input is 16 bit and your IC is too, it will be done
automatically.
‣ Second input (HTP merge): This will merge the selected universes together and transmit
the merged signals to the designated output. Enter the desired universe, start channel and
the number of channels you want to merge.
Advanced output
Bypass master dimmer: Enable if you want this output not to be dimmed by a master
‣
dimmer or brightness trigger.
Max time until resend: When no signal is received within a given time the current output is
‣
resent to the IC's (LEDs). This is used to prevent data issues and IC timeout functions
from happening because some IC's will switch to a default color or sequence when no SPI
is received for a certain duration. This may also result in a decrease of frame rate (FPS).
Reset this value to its default by pressing delete > generate a new universe again by
selecting the blue + button of the specific D port.
When you are finished adjusting the advanced options, click 'save' to store the settings.
TIP: In order to quickly test your outputs, you can toggle all ports on to full white when clicking
the bulb icon.

Network settings

Home > Settings > Network
This page shows a tab for both Ethernet (wired) and Wi-Fi (wireless) network related settings of the
DiGidot C4.
MAC Address
This is the unique the device MAC Address. This address cannot be changed and is being used for
identification and network communication.

Ethernet configuration

IP Address
The ethernet IP Address of the DiGidot C4.
Subnet-mask
Network broadcast range of your device.
Smart ethernet DHCP
Enable or disable the smart DHCP server. When enabled the DiGidot C4 will assign IP Addresses to
devices that connect trough ethernet.
C4 Manual Version 2.2.0 56-78
