Art-Net, sACN or DMX triggers

Home > Triggers > click '+' to add a trigger > select 'Art-Net, sACN or DMX'
You can use Art-Net, sACN and/or DMX to trigger various actions.
Art-Net/sACN triggers (default)
If this..
‣ Input universe: Select the input universe of the incoming signal.
Channel: Select the channel that is used for this trigger.
‣
Minimum: Define the minimum channel value (0-254)
‣
Maximum: Define the maximum channel value (1-255).
‣
DMX triggers
How to configure ports as DMX in?
You can configure the ports D1-D4 to one or two DMX inputs.
In case that port D1 & D2 and/or D3 & D4 are available (if no SPI protocol has been configured for
these ports), you can choose which ports you want to configure as DMX input.
If all ports are already in use you have to re-configure the input/output configuration:
Home > Settings > In/out configuration
NOTE: DMX uses two lines for data; DMX + and DMX - and therefore requires two DiGidot C4
ports.
If this..
Select DMX port: Select the DMX port where the trigger signal is coming from.
‣
‣ Channel: Select the channel that is used for this trigger.
Minimum: Define the minimum channel value (0-254)
Maximum: Define the maximum channel value (1-255).

Power up

Home > Triggers > select '+' to add a trigger > select 'Power up'
This trigger will perform an action as soon as the DiGidot C4 booted or when the device is rebooted
after performing a system restart.
If this..
Automatically starts after DiGidot C4 start up
‣

Onboard button

Home > Triggers > select '+' to add a trigger > select 'Button'
The onboard button of the DiGidot C4 can be programmed to trigger various actions.
