Global configuration
This page offers advanced configuration item options that apply to all selected devices.
Such as;
‣ Gamma Correction
Color profile
‣
Fallback options
‣
IP Address filter
‣
Input watcher
The input watcher is a useful tool that monitors incoming control signals. You can switch between:
‣ Art-Net/sACN: you can select a specific universe that you want to monitor
DMX: switch between the inputs if you have configured one or more ports as DMX In.
‣
Limit outputs
On this page you can set the master brightness, the brightness limiter and the adaptive power
limiter.
Brightness limiter
This option limits the individual channels to a specific percentage. This means that every
channel or LED will never exceed this percentage.
E.g.: Limiting brightness to 50%, means that all individual channels can never exceed 50% but
the control range per channel will remain the same. Effectively the percentage is applied to
the input value for each channel.
Adaptive power limiter
This option limits the total average output of all channels combined to a specific percentage
in order to decrease total power consumption. Individual channels may still output up to
100%.
E.g.: Limiting power to 50% means that half of the channels can output 100% and the other
half at 0% or all channels at 50%, etc.
In case you would try to output all channels to 75%, the output of all channels would be
automatically limited to a total 50%, but will maintain ratios relative to each other.
Delete configuration
Deletes all IO configuration settings of selected devices.

In/out configuration item page

Home > Settings > In/out configuration > Universe item
