Record Settings - DiGidot C4 Extended Manual

When the record is completed, you can play and stop the recorded scene. A trimming slider can be
used to adjust the beginning and end point of the record. You can choose multiple options before
saving the record. Below you can find all record options.
Record options
Time based
Adjust the start and end time to trim the record to its desired length.
Frame based
Adjust the start and end frame trim the record to its desired length.
Find loop
This option detects if there is a loop in the record (within the trimmed section) and automatically
creates a looped record.
Trim black
This option detects if there are any black frames at the beginning and end of the trimmed selection
and trims the length of the entire record.
No effect
This will keep the original trimmed record.
Fade
This option creates a fading transition from the end to the start of the record. You can manually
adjust the fading time before the record is saved.
Note that this option only appears when the record is long enough to generate this effect.
Pingpong
This option replays the trimmed record from beginning to end and then from the end to the
beginning again.
Recording DMX
Go to Home > Settings > In/out configuration > Select a port and choose 'DMX Input'
In order to record from DMX, you have to configure one or two DMX Input(s) in the I/O configuration.

Record settings

Home > Create scenes > Record settings
On this page you can select and deselect the incoming universes that can be recorded. It will also
show the FPS (frame per second) of the incoming signal for each DiGidot C4.
Use Art-Net to start, stop and save records
This option allows you to trigger following record functions: prepare record buffers, start, stop and
save records with an Art-Net signal.
To create an Art-Net trigger you need to specify a universe number, a channel number and a
minimum and maximum DMX/channel value between 0 and 255, to determine when the event should
be triggered. These triggers can also be created manually on the 'Home > Triggers' page.
C4 Manual Version 2.2.0 35-78
