Custom

This trigger opens a note pad where custom trigger code can be entered. This option is usually
reserved for developers or custom-made code.
Action examples:
Open editor: This will open the custom command in a in browser editor.

Creating linked triggers

Home > Triggers > Linked triggers
Linked triggers are used to link input triggers to actions with variable values such as linking an
analog input to the master brightness.
On this page it's possible to link the trigger input on the left to an action on the right. Simply select
an input and an action to connect a trigger permanently. The established link is visualized by a
connected line between the two items.
Parameters that can be controlled by linked triggers are:
Speed
‣
‣ Hue (color)
‣ Saturation
Brightness
‣
Playlist
‣
OSC -
‣
OSC commands must be send to port 8000
‣ UDP -
UDP commands must be send to port 6467
Further information about OSC and UDP triggers can be found here:
Home > Triggers > click on the 3 dots in the top right blue bar > select 'HTTP, UDP and OSC'
For some of these parameters it's possible to define a specific control range by adjusting the sliders.
For the analog, Art-Net, sACN and DMX inputs it's required to set a minimum and maximum input
value.
Some triggers and some actions require further configuration, such as OSC and UDP where custom
messages can be set.
NOTE: The number of triggers that you can generate is limited due to available memory.
Available memory is affected by the license, number of configured universes, number of
actions, scenes that are playing, etc. In any case, the maximum number of triggers is around
25. If too much triggers are created, this can result in memory overload and will cause a device
crash. In such cases, it's best to remove the microSD card, make a copy of the microSD card,
delete the contents of the triggers folder and insert the microSD card again. New triggers can
be created but you should create less triggers than before.

Trigger watcher

Home > Triggers > Click the three dots in the top right blue bar > Trigger Watcher
C4 Manual
Select an action from the pop-up window.
