Flags

Bit
0
1-3
4
5-7
8
9-15
Table 91: Packet periods flags
10.11.1.2

Clear Existing Packets

This is a boolean field, when set to one it deletes any existing packet rates. When set to zero
existing packet rates remain. Only one packet rate can exist per packet ID, so new packet rates will
overwrite existing packet rates for the same packet ID.
10.11.1.3

Packet Period

This indicates the period in milliseconds. The packet rate can be calculated as follows.
Packet Rate = 1000/(Packet Period) Hz
For example setting packet ID 20 with a packet period of 50 will give the following.
Packet 20 Rate = 1000/(50)
Packet 20 Rate = 20 Hz
10.11.2

Baud Rates Packet

Packet ID
Length
Field #
Bytes
Offset
1
0
2
1
3
5
4
9
Table 92: Baud rates packet
Clear existing packet periods, see section 10.11.1.2
Baud Rates Packet
Data
Size
Type
u8
1
u32
4
u32
4
8
GNSS Compass Reference Manual
Description
Permanent
Port
Port field valid
Reserved
Reserved
Primary serial port baud rate (1200 to 1000000)
Secondary serial port Baud Rate (1200 to 1000000)
Reserved (set to zero)
Page 75 of 85
Version 1.1
13/01/2021
182
17
