Certification - Advanced Navigation GC-SER-LC Reference Manual

Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Table 18: Unterminated serial cable pin allocation table
7.12

Certification

The GNSS Compass is designed to meet IMO wheelmark for MED/4.7 Speed and Distance
Measuring Equipment (SDME) and MED/4.41 Transmitting Heading Device (THD, GNSS method)
based on the Directive 2014/90/EU.
Models GC-SER-LC and GC-SER-HA are pending certification to the following standards.
IMO Standards
IMO Res.MSC 116(73)
IMO Res.MSC 191(79)
IMO Res.A.694(17)
Table 19: Standards for GC-SER-LC and GC-SER-HA
Models GC-POE-LC and GC-POE-HA are pending certification to the following standards.
Colour
Red
Black
Green
Green/White
Purple
Purple/White
Brown
Brown/White
Pink
Pink/White
Grey
White
Blue
Orange
Orange/White
Yellow
Grey/White
Bare
GNSS Compass Reference Manual
Page 30 of 85
Version 1.1
13/01/2021
Function
Power Supply
Power Ground
Primary RS422 Tx(+) / RS232 Tx
Primary RS422 Tx(-)
Primary RS422 Rx(+) / RS232 Rx
Primary RS422 Rx(-)
Secondary RS422 Tx(+) / RS232 Tx
Secondary RS422 Tx(-)
Secondary RS422 Rx(+) / RS232 Rx
Secondary RS422 Rx(-)
Signal Ground
CAN Hi
CAN Lo
Alarm Hi
Alarm Lo
1PPS Out
Signal Ground
Drain Wire (attach to power ground)
ISO/IEC Standards
ISO 22090-3:2014
IEC 60945 (2002) incl. IEC 60945 Corr. 1 (2008)
IEC 61162-1 ed4.0 (2010-11)
IEC 61162-2 ed1.0 (1998-09)
IEC 62288 Ed. 2.0 (2014-07)
