10.10.39

Automotive Packet

Packet ID
Length
Field #
Bytes
Offset
1
0
2
4
3
8
4
12
5
16
6
20
Table 89: Automotive packet
10.11

Configuration Packets

Configuration packets can be both read from and written to the device. On many of the
configuration packets the first byte is a permanent flag. A zero in this field indicates that the
settings will be lost on reset, a one indicates that they will be permanent (i.e. stored in flash).
10.11.1

Packets Period Packet

Packet ID
Length
Field #
Bytes
Offset
1
0
2
2
3
3
+
Table 90: Packets period packet
Automotive Packet
Data
Size
Type
fp32
4
fp32
4
fp32
4
fp32
4
fp32
4
4
Packets Period Packet
Data
Size
Type
u16
1
u8
1
u32
4
GNSS Compass Reference Manual
Description
Virtual odometer distance (m)
Slip Angle (rad)
Velocity X (m/s)
Velocity Y (m/s)
Distance standard deviation (m)
Reserved (set to zero)
2 + (5 x number of packet periods)
Description
Flags, see section 10.11.1.1
Packet ID
Packet period, see section 10.11.1.3
Fields 2-34 repeat for additional packet periods
Page 74 of 85
Version 1.1
13/01/2021
73
24
181
