10.10.1.1

System Status

This field contains 16 bits that indicate problems with the system. These are boolean fields with a
zero indicating false and one indicating true.
Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Table 40: System status
GNSS Compass Reference Manual
Description
System Failure
Accelerometer Sensor Failure
Gyroscope Sensor Failure
Magnetometer Sensor Failure
Secondary GNSS Failure
Primary GNSS Failure
Accelerometer Over Range
Gyroscope Over Range
Magnetometer Over Range
Reserved
Minimum Temperature Alarm
Maximum Temperature Alarm
Low Voltage Alarm
High Voltage Alarm
GNSS Antenna Fault
Data Output Overflow Alarm
