10.11.7.2

Transmit Functions

Value
0
7
12
39
40
41
42
Table 102: Port transmit functions
10.11.7.3

Receive Functions

Value
0
6
11
19
42
Table 103: Port receive functions
10.11.8

Set Zero Orientation Alignment Packet

Packet ID
Length
Field # Bytes
Offset
1 0
2 1
Table 104: Set zero orientation alignment packet
10.11.9

Reference Point Offsets Packet

The reference point offsets packet can be used to adjust the measurement point that all data is
referenced to. By default all the values of this packet are zero and the measurement point that all
data is referenced to is the centre of the GNSS Compass unit. The primary reference point offset
can be used to adjust the measurement point to a different location on the vehicle. The primary
reference point offset applies to all data output including NMEA etc as well as heave point 1. The
other heave point offsets apply only to heave points 2-4 in the Heave Packet.
RTCM Differential Corrections Input (default)
Set Zero Orientation Alignment Packet
Data Size
Type
u8 1
u32 4
GNSS Compass Reference Manual
Description
Inactive
NMEA Output (default)
ANPP Output
TSS1 Output
Simrad 1000 Output
Simrad 3000 Output
Serial Port Pass-through
Description
Inactive
NMEA Input
ANPP Input
Serial Port Pass-through
Description
Permanent
Verification sequence (set to 0x9A4E8055)
Page 81 of 85
Version 1.1
13/01/2021
