Filtering Available EDID
Use the Filter tab (see figure 17,
displayed in the Favorites, Connected Outputs, and Available EDID panels.
1.
From the Resolution drop-down menu (
2.
From the Refresh Rate drop-down menu (
From the Video Format drop-down menu (
3.
From the Audio Format drop-down menu (
4.
5.
To set the filters back to the default, click the Clear button (
Assigning EDID
To assign EDID to the input:
From the Input box in the EDID Assignment panel (
1.
2.
From the Favorites, Available EDID, or Connected Outputs panel on the left,
select the desired EDID.
3.
Then either:
Click the Assign button (
•
Drag and drop EDID image from the Favorites, Available EDID, or Connected
•
Outputs panels to the Input box.
4.
Alternatively, click Assign to All (
Adding EDID to the EDID Library
1.
Click the Add EDID to Library button (
window opens (see figure 18).
Figure 18.
Browse Add EDID to the Library Window
2.
Navigate to the desired EDID file location and select it (
NOTE: Valid EDID files have a .bin file extension.
3.
Click the Open button (
on page 26) to limit the number of available EDID
2
), select a specific resolution or Any.
3
), select a specific refresh rate or Any.
4
), select HDMI or Any.
5
), select LPCM‑2Ch, None or Any.
6
) to assign EDID to the input, OR
9
) to assign the same EDID to all the inputs.
¢
). The Browse Add EDID to Library
£
). The EDID is added to the Available EDID panel.
2
DTP2 T 212 • Configuration Software
).
7
), select the input.
8
).
1
27
