ISS 608 and ISS 612 • Setup Guide (Continued)
Step 5 - Genlock connections (ISS 612 only)
Genlock input connector — Connect an external genlock signal to this connector (see figure 1,
•
• Loop Out connector — Connect any downstream equipment that requires genlocking to this connector (
Step 6 — Connect Control Devices
LAN (Ethernet) connector — (Optional) Connect a network WAN or LAN switch, a control system, or computer to the
•
Ethernet RJ-45 port (
IP address: 192.168.254.254
•
Configure Network Settings
See
• Remote RS-232 connector — (Optional) Connect a control system or computer to the rear panel bidirectional RS-232 serial
). The default baud rate is 9600.
port ( J
USB Config connector — (Optional) Connect a computer to the front panel USB mini-B port (see figure 4,
•
Step 7 — Power
AC power connector — Connect a 100 to 240 VAC, 50 - 60 Hz power source to the AC power connector (see figure 1,
Power Up
Apply power by connecting
the power cord to an AC
source. The switcher performs
a self-test that displays the
model name and the firmware
version in the LCD screen.
After approximately 2 seconds,
the LCD screen reverts to its
default display cycle, alternating
between three displays: two
showing the selected program
and preview inputs and their rates, and the third showing the selected output rate.

Front Panel Operations

1 2
MUTE FREEZE
1 2
MUTE FREEZE
A A
Figure 4.
ISS 612 Front Panel
A
MUTE and FREEZE buttons
B Input selection buttons
NOTE: The ISS 608 front panel has 8 PROGRAM and 8 PREVIEW input buttons.
Select an Input
Press and release the desired PROGRAM or PREVIEW input selection button (see figure 4,
input displays on the program or preview monitor. Press the MUTE or FREEZE buttons (
PREVIEW output video.
2
I ). Defaults:
Subnet: 255.255.255.0
•
on page 4 to view or change the settings.
Power
Electronics
on
Extron
ISS 608
PROGRAM
3 4 5 6 7 8 9 10 11 12
PREVIEW
3 4 5 6 7 8 9 10 11 12
B B
C
Effects buttons
D Presets and TAKE buttons
Gateway: 0.0.0.0
•
Extron
60-1684-01
FW Ver 1.00
EFFECTS PRESETS ADJUST
RECALL
DISSOLVE CUT SIZE
SAVE
VIDEO
ENTER
WIPE POSITION
KEY
CONFIG
MENU
PIP LOGO TAKE
TAKE
C C D D E E F F
E
Adjust buttons
F USB Config port
K
on page 1)
L ).
• DHCP: Off
F
Default Display Cycle
Prog #01 HDMI Prev #08 DP
720p @60 Hz
1080p @60Hz
2
sec.
2
Output Rate
sec.
1080p @60Hz
ADJUST
NEXT
ISS 612
INTEGRATION SEAMLESS SWITCHER
G G H H
G
Menu navigation controls
H LCD screen
B ). The button lights and the selected
A
) to mute or freeze the PROGRAM or
).
A
).
2
sec.
