Completing The Setup - GE LOGIQ V3 Basic Service Manual

3-5-3-2 Physical dimensions
Table 3-3:
Height
1344 (system with 15"
LCD Monitor)
1399 (system with 17"
LCD Monitor)
1415 (system with 19"
LCD Monitor)
52.91 (system with 15"
LCD Monitor)
55.08 (system with 17"
LCD Monitor)
55.71 (system with 19"
LCD Monitor)
3-5-3-3 Console Weight
LOGIQ V3/V5/V5 Expert – Basic Service Manual
5726264-100 English Rev.8
Physical dimensions of LOGIQ V3/V5/V5 Expert
Width
455
17.9
• Weight (system with 15" LCD Monitor): approx. 43 kg (95
lbs)
• Weight (system with 17" LCD Monitor): approx. 45 kg (99
lbs)
• Weight (system with 19" LCD Monitor): approx. 48 kg (106
lbs)

Completing the setup

Depth
722
28.43
Unit
mm
Inches
3-15
