3-7-3 Peripherals Installation Instructions

3-7-3-1 Sony UP-D711MD Printer Installation
3-7-3-1-1 Tools
3-7-3-1-2 Manpower
3-7-3-1-3 Preparations
3-7-3-2 Installation Procedure
NOTE:
LOGIQ V3/V5/V5 Expert – Basic Service Manual
5726264-100 English Rev.8
No special tools needed.
One person 5 min.
1. Unpack B/W Printer.
2. Ensure no physical damage.
The printer driver is customized for the LOGIQ V3/V5/V5 Expert
at the factory, you do not need to change the settings.
1. UP-D711MD Printer can be properly connected using USB
Ports.
Figure 3-12. Connect UP-D711MD to LOGIQ V3/V5/V5 Expert
Sony UP-D711MD Printer is connected to LOGIQ V3/V5/V5
Expert system via the USB port under the control panel.
Peripherals Installation
3-29
