4900002277
Parameter
Bus address
Baudrate
Data transfer mode
Parity
Byte order
Failure mode
1) Not a Number
94
Description
Enter device address.
Define data transfer speed.
Select data transfer mode.
Select parity bits.
Select byte transmission sequence.
Select measured value output
behavior when a diagnostic mes-
sage occurs via Modbus communi-
cation.
1)
NaN

Displaying the I/O configuration

The I/O configuration submenu guides the user systematically through all the
parameters in which the configuration of the I/O modules is displayed.
Navigation
"Setup" menu → I/O configuration
User Entry
1 to 247
• 1200 BAUD
• 2400 BAUD
• 4800 BAUD
• 9600 BAUD
• 19200 BAUD
• 38400 BAUD
• 57600 BAUD
• 115200 BAUD
• ASCII
• RTU
Picklist ASCII option:
• 0 = Even option
• 1 = Odd option
Picklist RTU option:
• 0 = Even option
• 1 = Odd option
• 2 = None / 1 stop bit
option
• 3 = None / 2 stop bits
option
• 0-1-2-3
• 3-2-1-0
• 1-0-3-2
• 2-3-0-1
J22 TDLAS Gas Analyzer
Factory Setting
247
19200 BAUD
RTU
Even
1-0-3-2
