J22 TDLAS Gas Analyzer
SpectraSensors, Inc.
Display area
Menus
Symbol
Operation
Appears:
•
In the menu next to the "Operation" selection
•
At the left in the navigation path in the Operation menu
Setup
Appears:
•
In the menu next to the "Setup" selection
•
At the left in the navigation path in the Setup menu
Diagnostics
Appears:
•
In the menu next to the "Diagnostics" selection
•
At the left in the navigation path in the Diagnostics menu
Expert
Appears:
•
In the menu next to the "Expert" selection
•
At the left in the navigation path in the Expert menu
Submenus, wizards, parameters
Symbol
Submenu
Wizard
Parameters within a wizard
No display symbol exists for parameters in submenus.
Locking
Symbol
Parameter locked
When displayed in front of a parameter name, indicates that the
parameter is locked.
•
By a user-specific access code
•
By the hardware write protection switch
Meaning
Meaning
Meaning
