Controller

Different LEDs in the controller provide information on the device status.
1 Supply voltage
2 Device status
3 Not used
4 Communication
5 Service interface (CDI) active
LED
1 Supply voltage
Data transfer active
Connection lost
Not using optimum ver-
sion of Web server.
Unsuitable view settings.
• JavaScript not enabled
• JavaScript cannot be
enabled
Color
Off
Green
4900002277
Wait until data transfer or
current action is finished.
Check cable connection
1.
and power supply.
Refresh the Web brow-
2.
ser and restart if
necessary.
Use the correct Web
1.
browser version .
Clear the Web browser
2.
cache and restart the
Web browser.
Change the font size/
display ratio of the Web
browser.
Enable JavaScript.
1.
Enter http://
2.
XXX.XXX.X.XXX/
basic.html as the IP
address.
Meaning
Supply voltage is off or too low
Supply voltage is ok
A0029629
