Endress+Hauser SpectraSensors J22 TDLAS Operating Instructions Manual page 126

4900002277
Diagnostic
Short Text
Number
301 SD card error
302 Device verification
active
303 I/O @1 configuration
changed
311 Electronic failure
330 Flash file invalid
331 Firmware update fai-
led
332 Writing in embedded
HistoROM failed
361 I/O module 1 to n
faulty
372 Sensor electronic
module(ISEM) faulty
373 Sensor electronic
module(ISEM) faulty
375 I/O - 1 to n communi-
cation failed
382 Data storage
383 Memory content
120
Remedy Instructions
Check SD card.
1.
Restart device.
2.
Device verification active, please wait.
Apply I/O module configuration
1.
(parameter 'Apply I/O configuration').
Afterwards reload device description
2.
and check wiring.
Do not reset device.
1.
Contact service.
2.
Update firmware of device.
1.
Restart device.
2.
Update firmware of device.
1.
Restart device.
2.
Replace user interface board Ex d/XP:
replace controller
Restart device.
1.
Check electronic modules.
2.
Change I/O Modul or main electro-
3.
nics.
Restart device.
1.
Check if failure recurs.
2.
Replace ISEM.
3.
Transfer data or reset device.
1.
Contact service.
2.
Restart device.
1.
Check if failure recurs.
2.
Replace module rack inclusive elec-
3.
tronic modules.
Insert T-DAT.
1.
Replace T-DAT.
2.
Restart device.
1.
Delete T-DAT via 'Reset device' para-
2.
meter.
Replace T-DAT.
3.
J22 TDLAS Gas Analyzer
Diagnostic
Status Signal
Behavior
(from factory)
(from factory)
C Warning
C Warning
M Warning
M Warning
M Warning
F Warning
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
F Alarm
SpectraSensors, Inc.
