Output Values For Switch Output; Output Values For Relay Output - Endress+Hauser SpectraSensors J22 TDLAS Operating Instructions Manual

J22 TDLAS Gas Analyzer
Parameter
Output current 1
Measured current
Parameter
Switch status 1 The Switch option
to n is selected in the
Operating mode
parameter.
SpectraSensors, Inc.
Parameter overview with brief description
Description
Displays the current value currently calcu-
lated for the current output.
Displays the current value currently mea-
sured for the current output.

Output values for switch output

The switch output 1 to n submenu contains all the parameters needed to display
the current measured values for every switch output.
Navigation
"Diagnostics" menu → Measured values → Output values → Switch output 1 to n
Switch output 1 to n
Parameter overview with brief description
Prerequisite
Displays the current
switch output status.

Output values for relay output

The Relay output 1 to n submenu contains all the parameters needed to display
the current measured values for every relay output.
Navigation
"Diagnostics" menu → Measured values → Output values → Relay output 1 to n
Relay output 1 to n
Switch status 1 to n
User Interface/
Description
•
•
Switch status
Switch cycles
Max. switch cycles number
User Interface
3.59 to 22.5 mA
0 to 30 mA
Factory Setting
User Entry
Open —
Closed
