Operation

Detailed information:
• On the basic settings for the local display→  66
• On the advanced settings for the local display →  73
With the Measured values submenu, it is possible to read all the measured values.
Navigation
"Diagnostics" menu → Measured values
Measured values

Output values

The Output values submenu contains all the parameters needed to display the
current measured values for every output.
Navigation
"Diagnostics" menu → Measured values→ Output values
Ouput values

Output values of current output

The Value current output submenu contains all the parameters needed to display
the current measured values for every current output.
Navigation
"Diagnostics" menu → Measured values → Output values → Value current output 1
to n
Current output 1 to n
Output values
Current output 1 to n
Switch output 1 to n
Relay output 1 to n
Output current 1 to n
Measured current 1 to n
