FP PostBase Vision Reference Manual page 178

178
PostBase Vision
Remove PostBase Vision from feeder
Remove letter catch tray
The connections / interfaces of the
PostBase Vision franking machine are
described in the figure on page 14.
• Lift the front of the franking machine about
5 cm.
• Move the letter catch tray away to the right.
• Put the franking machine back down.
To feed mail pieces, the hand feed tray or
the sealer or the feeder are positioned to the
left of the franking machine.
The housings of the franking machine and
the feeding device in use are mechanically
coupled via catches (on the right side of the
feeding device) and slots (in the franking
machine's housing).
• Carefully lift the franking machine at the
housing and remove it from the feeding
device at hand.
• Place the franking machine on a firm, level
base.
