G 1xxx/G 2xxx
Temperature (°F (°C))
Table 050-2: Temperature Sensor R30 Resistance Values
2.15
Turbidity Sensor (ECO Sensor III, Autosensor), B3/10
G 1xxx/G 2xxx dishwashers are provided with one of two turbidity sensors,
depending on model. The ECO sensor III measures the turbidity of the water
and, based on this result, the wash blocks, temperatures and running times of
Sensor Wash programs are modified. In addition to this, the Autosensor has
a microprocessor to evaluate the particle measurement.
Principle of operation:
Water circulation and the presence of detergent cause bubbles to be
developed in the suds and measurement technology cannot differentiate
between these bubbles and suspended soil particles. With the Autosensor, a
proportion of the suds are directed into a bypass channel which is wider at
one end. This causes the flow rate to reduce and hence the bubbles in the
water to rise. The suspended soil particles in the water can then be more
Temperature Sensor R30 Resistance Values
32 (0)
41 (5)
50 (10)
59 (15)
68 (20)
77 (25)
86 (30)
95 (35)
104 (40)
113 (45)
122 (50)
131 (55)
140 (60)
149 (65)
158 (70)
167 (75)
176 (80)
185 (85)
194 (90)
199 (93)
203 (95)
93
Technical Information
Resistance (kΩ)
35.979
28.519
22.766
18.281
14.774
11.982
9.787
8.048
6.653
5.523
4.608
3.856
3.243
2.745
2.333
1.990
1.704
1.464
1.262
1.157
1.093
