G 1xxx/G 2xxx
Figure 080-3: Selected Options
10. When finished customizing the program, confirm with OK.
11. Select Start.
2.1.3
Incognito Controls
1. Make sure that the spray arms are not blocked.
2. Turn on the dishwasher by touching the I control.
3. The main menu is shown in the display. See Figure 080-4.
4. Select the desired program.
Figure 080-4: Incognito Main Menu
5. Select the desired program according to the type of load and soiling.
6. The display changes to the program menu.
7. Options can be added to the selected program. See Figure 080-5.
Figure 080-5: Selected Program Display
Note:
Information about the selected program can be displayed by touching the i
control.
8. Select the desired options; a √ will appear next to the option selected.
9. When finished customizing the program, confirm with OK.
10. Select Start.
11. Close the door.
2.2
Component Test
After selecting the service mode (Section 080-4.3) and successfully
accessing the component test program, individual electrical components can
be activated via the program selection button or the Start/Stop button,
depending on model. During this procedure, certain components can only be
activated via special mini-programs.
125
