Proxy Setup
Proxy is the registered /proxy sip server. The Proxy
Setup Info page allows you to set the following
required server's VoIP parameters:
Proxy User Name allows you to enter

alphanumeric characters in this field using the
editor screen to create a name.
Proxy Port is a numeric value of the proxy port

used to establish an IP network session.
Address Format is either IP Address or DNS

Name.
Proxy Domain allows you to enter either the

address of the IP or name of the domain server.
Proxy Password allows you to set a password for the proxy domain.

To setup the proxy info:
1. Press the up/down arrow keys to select the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press
editor screen and use the navigation keys to scroll through.
4. Press
G.fast/VDSL2/ADSL2+ Multi-play Test Set
on a value to open a list box of options or the alphanumeric
to confirm the value.
Setting Up DSL/IP Tests
Test Setup
61
