Setting Up DSL/IP Tests
Test Configuration
G.INP allows you to Enable/Disable the standards based Physical

Layer Retransmission scheme for impulse noise protection. This entry
applies only to Auto and Manual tests.
NAT (network address translation) allows you to Enable/Disable the

translation of the IP addresses of computers in a local network to a
single IP address. NAT is available only if Access Mode is set to DHCP ,
Static, or IPoA.
Note: For Ethernet Test Setup, NAT is available only for GVXAA and GVXAB
models.
Login to WAN (Data Test) (in Manual Test Setup only) can be set to

one of the following, when running a Manual Test:


This parameter can not be selected for the following Access Modes:
Sync Only, Bridged, and IPv6 (DHCP), and will be set to Auto.
The following parameters are available only when Access Mode is PPPoE
or PPPoA.



50
Auto will start the WAN login automatically right after Show Time.
Manual enables a Login button on the WAN Status page, once
Show Time is reached. You must press the button to start the WAN
login.
Login Name/Password is your user ID and password.
Obtain IP is either Dynamic where the access concentrator or
broadband remote access server assigns a temporary IP address to
the unit, or Static where you enter the IP address of the unit.
Static IP is the address of the current location assigned by the
service provider. This entry is available only if Obtain IP is set to
Static.
