EXFO MaxTester 630G User Manual page 103

Function Keys:






To dial a number:
1. Use the up/down arrow keys to highlight an entry or button and
press
2. Enter a new number using the on-screen keypad or select an existing
one from the lists.
3. Press the Dial function key to start the call.
G.fast/VDSL2/ADSL2+ Multi-play Test Set
Dial/Hang Up button allows you to dial the selected or entered
number, or disconnect the dialed call.
Add To PhoneBook saves the entered number to the Phone Book.
Mute/Unmute Speaker changes the speaker status.
Volume adjusts the volume level.
DTMF opens the DTMF keypad. If the call is not in progress or
connected, this button is disabled.
.
Running DSL/IP Tests and Viewing Results
VoIP Call
97
