Setting Up DSL/IP Tests

DSL Main Menu Page

DSL Main presents the main menu page which allows
you to navigate to each icon using the up/down
left/right arrow keys on the keypad. Press
access a test or bring up the sub-menu of the selected
icon:
For Auto, Manual, or Ethernet, the test will start

and the screen control will navigate to the
Connection Summary page.
Result Manager opens a list of file names

previously saved tests, to view, upload, export, or
delete results.
Test Configuration provides the utilities to configure test parameters.

Setup opens a sub-menu displaying the following:




G.fast/VDSL2/ADSL2+ Multi-play Test Set
Modem Settings allows you to set the display and power
parameters of the modem.
Application Settings allows you to preset the unit with specific
DSL measurement values.
VoIP Phone Book allows you to manage phone numbers relevant
to performing VoIP tests.
to
