The following parameters are available only when Access Mode is IPoA or
Static.






The following parameters are available only when the test setup is for
Ethernet.
WAN/LAN Link Speed is always set to Auto (GVXAA and GVXAB
models only).


Note: GVXAA and GVXAB models also support 1000 Mbit/s.
To configure the setup options:
1. Press the up/down arrows to select the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press
editor screen and use the navigation keys to scroll through.
G.fast/VDSL2/ADSL2+ Multi-play Test Set
IP Address is the address for the unit that is actively connected to
your network or the internet at the time of login.
Gateway is the IP address of the default gateway.
Verify Gateway can be set to Enable or Disable.
Subnet Mask is the network address used to identify if the IP
address is within the same wide area network.
DNS1 is the address of the primary domain name server to be used
by the unit. If DNS is unavailable, enter 0.0.0.0.
DNS2 is the address of the secondary domain name server to be
used by the unit. If DNS is unavailable, enter 0.0.0.0.
WAN/LAN Link Speed is a choice between Auto (negotiated
during the link establishment), 100, or 10 Mbit/s.
WAN/LAN Connect Mode is Full- or Half-Duplex, when Link
Speed is set to 100, or 10 Mbit/s.
on a value to open a list box of options or the alphanumeric
