Modem Power OFF:



Power Save Mode is either Disable/Enable. When enabled, BATTERY

Idle timeout and BATTERY suspend timeout are set to 5 min,
Backlight to 50 %, and Modem Power OFF (including the unit) to
Immediately. The selections are limited and the following warning
message will popup:
Power Save mode is enabled. High Voltage Monitoring is active
only while the test is in progress.
Default power scheme settings are:
LCD backlight turns off after system idles (no keys pressed) for 10 min.

Unit switches to suspend mode after timeout: 10 min.

Power Save Mode is Disable requiring you to go to this page to see

what will be changed before enabling it.
The chart displays the following battery measurements: capacity, current,
and voltage. Battery Status indicates the current power level, as a
percentage, for the battery. Charging is shown as the status only in dual
battery pack units.
To change the power scheme settings:
1. Press
2. Under DC IN or BATTERY, use the arrow keys to select Idle/suspend
timeout modes. Press
the left/right arrow keys.
3. Select a new value, then press
the other modes as needed.
G.fast/VDSL2/ADSL2+ Multi-play Test Set
Immediately for when a DSL/IP test is completed or stopped. In
this mode, the modem is powered on when DSL/IP test starts.
Idle values power off the modem within a defined period after an
DSL/IP test is completed or stopped.
, select System Settings, and then Battery Info.
Setting Up the MAX-630G
to view the list of available choices or use
to confirm the choice. Repeat for
Battery Info
