R&D AND MANUFACTURING—OPTICAL
DISCONTINUED PRODUCT
Next-Generation Network Assessment
CABLE ASSEMBLY AND COMPONENT
Provides the most accurate insertion loss
and reflectance measurements on the market for
components and cable assemblies
High-sensitivity, mandrel-free reflectance measurements down to
–75 dB, meeting requirements for the most demanding FTTH applications
Simultaneous measurement on four wavelength (1310, 1490, 1550 and
1625 nm)
Open architecture allows for customizable controls and remote
configuration
Compatible with simplex, duplex, multifiber, bundle, hybrid and fanout
cable assemblies, as well as PLC splitters and planar arrays
Platform compatibility
IQS-600 Integrated Qualification System
IQS-500 Intelligent Test System
TEST SYSTEM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IQS-12001B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EXFO IQS-12001B

Summary of Contents for EXFO IQS-12001B

  • Page 1 IQS-12001B R&D AND MANUFACTURING—OPTICAL DISCONTINUED PRODUCT Next-Generation Network Assessment CABLE ASSEMBLY AND COMPONENT Provides the most accurate insertion loss and reflectance measurements on the market for components and cable assemblies High-sensitivity, mandrel-free reflectance measurements down to –75 dB, meeting requirements for the most demanding FTTH applications...

  • Page 2: Key Features

    Maximize production throughput for insertion loss (IL) and mandrel-free reflection testing for all types of fiber-optic interconnect cable and component assemblies with the IQS-12001B Cable Assembly and Component Test System. This fast and accurate system comes with the most complete single-software package available, delivering truly integrated testing for simplex, duplex, multifiber, hybrid and fanout fiber assemblies, as well as for components such as PLC splitters used in FTTx systems.

  • Page 3: System Overview

    APC connectors. Customizable modular architecture The IQS-12001B’s unique architecture allows you to add and remove modules to meet your testing needs. Mix and match different wavelength combinations, test singlemode and multimode cable assemblies, and add switches to convert your simplex configuration into a multifiber test system—thanks to the system’s unified software and powerful database, which protect your...
  • Page 4 Label printing utility, allowing users to design their own labels Customize it to fit your needs The IQS-12001B comes with DLL interfaces that enable you to create your own applications and remotely control your system. These system-level commands ensure smooth, efficient application creation without compromising the system’s measurement accuracy and speed.
  • Page 5 Calibration verification tool Reflectance referencing can also be achieved through the CKT-30 Singlemode Reflectance Reference module. Using the IQS-12001B’s reflectance verification wizard, you can perform a step-by-step verification of your system’s reflectance calibration. As long as it is within ≤...

  • Page 6: Standard Configuration

    IQS-12001B GPIB interface for test applications requiring more than 32 channels. The IQS-12001B lets you dedicate switch ports to specific connector types, which avoids having to disconnect the launch fiber, saving valuable setup time. For example, with a 1x32 switch, you can dedicate ports 1 to 24 to MTP connectors (male and female), ports 25 to 28 to MT-RJ connectors (male and female), and still have room for FC, ST, SC and MU connectors.

  • Page 7: General Specifications

    Relative humidity Laser Safety 21 CFR 1040.10 IEC 60825-1:2007 Standard Accessories Expansion units as required, user guide, certificate of compliance, custom report, label generator, IQS-12001B software and EUI-89 FC narrow key connector. Singlemode (1310/1550 nm) Singlemode < 6 < 6 1.8 to 1500...

  • Page 8: Ordering Information

    - Singlemode switch with FC/APC connector - Multimode switch with FC/PC connector - Other connectors available: contact EXFO for special order Example: IQS-12001B-10-S5-B-RHD-FOA-322-I3-SCM Optional Accessories FIP-400-USB2-DUAL: Video fiber inspection probe with USB 2.0 converter and software. FOA-U12: Universal 1.25 mm ferrule FOA-U25: Universal 2.5 mm ferrule...
