Setting Up the MAX-630G
Upload Setup
Ethernet is the default upload and if selected, displays an ethernet

icon
whether or not a connection is present displaying a green or yellow
icon similar to the Wi-Fi symbol described above.
Disable Upload option disables uploading your files via Wi-Fi or

Ethernet. You can export results to a USB memory device.
The DSL In-band Upload method supports DSL or Ethernet, and can be
set to either Enable or Disable.
Export to EXFO Connect Client allows you to Enable/Disable this
location to export your CQ and DSL test reports.
To select the Upload method:
1. Press
2. Select the Upload Enable tab.
3. Use the left/right arrow keys.
OR
4. Press
5. Use the up/down arrow keys to make your selection and press
confirm.
32
in the top right-hand corner of the navigation bar. It identifies
, select System Settings, and then Upload Setup.
to view the list of available choices.
to
