Running DSL/IP Tests and Viewing Results
WAN Status
WAN IPv6 parameter replaces the IPv4 Assigned IP , when IPv6

(DHCP) is set as the Access Mode in Connection Setup, because
there are 2 assigned IPv6 addresses: the global one (WAN) and the
local one (Link-Local).
Link-Local IPv6 is only displayed when IPv6 (DHCP) is set as the

Access Mode, and is the assigned local IPv6 address.
Gateway is the IP address of the default gateway.

Subnet Mask is the network address used to identify if the IP address is

within the same WAN.
DNS1 is the address of the primary domain name server to be used by

the unit.
DNS2 is the address of the secondary domain name server to be used

by the unit.
VPI (ATM mode only) is the virtual path identifier value, not available

in PTM mode.
VCI (ATM mode only) is the virtual circuit identifier value, not available

in PTM mode.
VLAN ID is a virtual local area network (VLAN) tag ranging from

0 through 4094. The entry is available only when VLAN Support is
Enable.
Test (for Manual Test only) allows you to select which triple play test

you want to run or results to view, along with their respective tabs:



The WAN info reflects the state of currently selected test.
92
Data Test - LAN Status and Data Tests Summary.
IPTV Test - Join Leave and IPTV Summary.
VoIP Test - VoIP Call and VoIP Summary.
