Using Screenshot Capture/Online Help

Using the Home/Help button, you can take a screenshot of the current
page display or view online help. If screenshots are Enabled, you will have
to select No in the popup message before accessing the online help. (See
below.)
Screenshot Capture
To take a screenshot:
Press and hold the Home/Help button to capture the current page and save
it with filename screenshot_ddmmyyyy_hhmmss where ddmmyyyy is
2-digit day, 2-digit month, 4-digit year; and hhmmss is 2-digit hour, 2-digit
minute, and 2-digit second. (The date and time value format is dependent
on the format selected in System Settings\Date and Time.)
Screenshots can be Enabled/Disabled from the System

Settings\Display and Language page.
If Enabled, press and hold the ? key to capture a screenshot on any

page.
A popup message is displayed saying Screenshot captured, Press

"Yes" to save or "No" to continue to Help. Pressing No will also
discard the screenshot.
Note: If you selected USB as the screenshot file location and no USB is connected
to the MaxTester, the following popup message is displayed: Screenshot
not saved, Insert USB and press "Yes" to save it or press "No" to
continue to Help.
Disabling Enable Screenshots will take you to the online help page

when pressing and holding the ? key, as previously described.
