Downstream/Upstream Max Bitrate displays the D/S (downstream)

and U/S (upstream) maximum attainable bit rates that the circuit can
handle as determined by the remote terminal and CO during the
training phase. Values can be greater than the actual bit rate.
If the Operation Mode is bonded, the 2-DSL line Max Bitrate is
combined.
Aggregate Data Rate (GVXAA and GVXAB models only) displays a

value of the gross bit rate if the Operation Mode is G.fast or
VDSL2-35b. Otherwise the value is N/A.
Downstream/Upstream actual bit rates are displayed by graphic bars

and the current actual values appear as numbers.


If the Operation Mode is bonded, the actual bit rate is a summary of
both DSL lines.
G.fast/VDSL2/ADSL2+ Multi-play Test Set
Downstream/Upstream bit rate values are shown in yellow region
if they are greater than Min threshold and less than OK threshold.
Downstream/Upstream bit rate values are shown in red region if
they are less than Min threshold.
