Upload Setup

Upload Enable
The Upload Enable function allows you to upload
your test result files.
The Out-band Upload Method allows you to use one
of the following methods:
Wi-Fi allows you to upload files from the

MaxTester via a Wi-Fi hotspot/router and is
available from the following results pages:


Note: Only channels 1 to 11 are supported on the Wi-Fi
hotspot/router.
A Wi-Fi symbol, in the top right-hand corner of the navigation bar,
identifies whether or not a connection is present. The Wi-Fi status is
indicated as follows:



G.fast/VDSL2/ADSL2+ Multi-play Test Set
Upload/Save Result tab
Result Manager/Upload
Green icon indicates that the MaxTester is connected with a Wi-Fi
hotspot.
Yellow icon indicates that the Wi-Fi dongle is powered up and ok,
but that the MaxTester is not connected to any Wi-Fi hotspot.
Red icon indicates a problem with the Wi-Fi (dongle not attached,
etc.).
Setting Up the MAX-630G
Upload Setup
