EXFO MaxTester 630G User Manual page 86

Setting Up DSL/IP Tests
Setup
File Name
The File Name tab sets up the standard configuration
for automatically naming a result file. You can only
Enable/Disable the entries. All enabled entries are
considered for file name generation.
File Name Preview displays a preview of the file

name. The actual values of the enabled entries
are not shown.
Date and Time value format depends on the

format selected in System Settings. This entry
cannot be disabled.
Separator allows you to choose a value to

separate the enabled entries in the file name, e.g.: Space ( ), Dash (-),
Underscore (_).
To select an entry and choose a value:
1. Press the up/down arrow keys to highlight the desired entry.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press
4. Press the up/down arrow keys to select the option and press
confirm your selection.
80
on a value to open a list box of options.
to
MAX-630G
