Open-Q™ 820 (APQ8096) / 820Pro (APQ8096SG) µSOM Development Kit User Guide Version 1.4
Description
GND GND
1.05V MB_ELDO_CAM1_DVDD
power rail
for camera
1
2.8V power MB_ELDO_CAM1_VCM
rail for
camera 1
(VDD)
GND GND
1.05V MB_ELDO_CAM2_DVDD
power rail
for camera
2
2.8V power VREG_L23A_2P8
rail for
camera 0, 2
(VDD)
1.8V power VREG_LVS1A_1P8
rail for
camera 0,
1, 2
5V power MB_VREG_5P0
rail for
camera 0,
1, 2

3.8.22 Ethernet AVB Expansion Header J73

This header is used for interfacing with automotive peripherals via Ethernet AVB standard.
Note that this is used for Intrinsyc internal testing and is not supported.
Signal Pin NO
J60[5]
J60[7]
J60[9]
J60[11]
J53[13]
J53[15]
J60[17]
J60[19]
Figure 26 J73 Ethernet AVB Expansion Header
Copyright Intrinsyc Technologies Corporation
Description
3.3V power MB_VREG_3P3
rail for
camera 0, 1,
2
2.85V power VREG_L18A_2P85
rail for
camera 1
(AVDD)
GND GND
3.3V power MB_VREG_3P3
rail for
camera 0, 1,
2
2.85V power VREG_L29A_2P8
rail for
camera 2
(AVDD)
GND GND
3.3V power MB_VREG_3P3
rail for
camera 0, 1,
2
12V power DC_IN_12V
rail for
camera 0, 1,
2
46
Signal Pin NO
J60[6]
J60[8]
J60[10]
J60[12]
J60[14]
J60[16]
J60[18]
J60[20]
