Table 3.7-1 Open-Q 820 / 820Pro µSOM Hardware Features
Subsystem / Feature Set
Connectors
Chipset APQ8096 or
APQ8096SG
PMIC (PM8996 &
PMI8996)
Memory 3GB LPDDR4
(4GB for 820Pro)
32 GB UFS
Connectivity Wi-Fi 2.4 GHz/
5GHz via
QCA6174 – SDIO
BT 2.4 GHz via
QCA6174 – UART
/ PCM
GPS via WGR7640
– SSBI
Qualcomm®
Proprietary
Protocol
RF Interfaces 2xWLAN / BT
1x GPS
Interfaces 3 x MIPI CSI
2 x USB HS & 1 x
USB SS
1 x MIPI DSI (DSI0
& DSI1) + Touch
100-pin display
Connector
3 X PCIe
Connector 3 x board to board
connector
Description
Qualcomm® Snapdragon™
820 Processor
Qualcomm® PMIC,
Companion PMIC for
APQ8096 processor
Memory POP
Primary Storage for platform.
Mainly used for storing SW
applications and user data
etc.
Wi-Fi Atheros QCA6174 Wi-
Fi + BT Combo Chip
Wi-Fi Atheros 6174
Wi-Fi + BT Combo Chip
GPS Frontend
Connect to antenna on
carrier board via coax cable
Connect to antenna on
carrier board via coax cable
Camera Connectors
CSI0, CSI1, CSI2
1 x USB3.1 header, 1 x dual
stack type A USB3.0 via USB
HUB for front USB (from
USB1 line), 1 x USB 2.0 via
switch (from USB1 line), 1 x
micro AB USB 2.0 (from
USB2 line)
100- pin display connector.
Interfaces with Intrinsyc
Display Adapter Board
PCIe 0 PCIe signal to Wi-Fi
module. PCIe 1, 2 routed out
of µSOM
Connectors to interface with
carrier board
15
Copyright Intrinsyc Technologies Corporation
Specification
Qualcomm® Kyro CPU, quad
core, 64-bit ARM V8 compliant
processor, 2.2GHz (2.34GHz
for 820Pro)
NA
Up to 1866MHz LPDDR4 POP
on CPU BGA chip. Supports
via 4x16bit channels
Toshiba UFS on board. Can
support up to 256GB
802.11a/b/g/n/ac 2.4/5.0 GHz
via QCA6174 over PCIe0.
Full 2x2 antenna configuration
Support BT 4.1 + HS and
backward compatible with BT
1.x, 2.x + EDR
GPS, GLONASS, COMPASS
2.4/ 5 GHz
GPS/GLONASS/COMPASS
MIPI Alliance Specification
v1.0
USB3.1 & USB2.0
MIPI Alliance Specification
v1.01. MIPI D-PHY
Specification v0.65,v0.81,
v0.90, v1.01
PCI Express Specification, Rev
2.1
Hirose DF40C series 100pin
connector
