o Supports I2C or SPI via BLSP12
o Can chose between I2C or SPI signals in SW U9 via BLSP12
Power specifications
The display connector supports the following power domains:
Display Signal
PM8996 LDO22 (3.3-2.8V)
PM8996 LDO14 (1.8V- 2.15V)
PM8996 LDO15(1.8V – 2.15V)
PM8996 S4A (1.8V)
Carrier 3.3V
Carrier 5 V
Carrier 12 V
The Intrinsyc Display Adapter is an additional PCB that mates with the display connector J2
on the carrier board. This board allows users to interface with the development kit via the
LCD that comes preinstalled on the display board. The following figure illustrates the
interfacing connectors on the display board.
Note: The display board comes as an additional add-on to the Open-Q 820 / 820Pro µSOM
development kit. To purchase this, please visit
sales@intrinsyc.com for details.
Note: Please refer to "Intrinsyc Open-Q 820 (APQ8096) Development Kit Technical Note 15:
Display Board Design Guide" for more information on designing a custom display board.
Power Domain
up to 150 mA
up to 150 mA
up to 300 mA
up to 300 mA
up to 0.5A
up to 1.5A
up to 0.5A
