Open-Q™ 820 (APQ8096) / 820Pro (APQ8096SG) µSOM Development Kit User Guide Version 1.4

3.5 Hardware Identification Label

Labels are present on the CPU board and the mini-ITX form-factor carrier board. The

following information is conveyed on these two boards:

CPU board (µSOM).:

• Serial Number

• WIFI MAC address

Refer to

http://support.intrinsyc.com/account/serialnumber

locating the serial number, as this will be needed to register the development kit. To

Mini-ITX form-factor carrier board:

• Serial Number

Note: Please retain the µSOM and carrier board serial number for warranty purposes.

The Open-Q 820 / 820Pro µSOM development platform consists of three major components

o Open-Q 820 / 820Pro µSOM

o Carrier board for I/O and connecting with external peripherals

o Display Adapter Board (additional accessory)

The following diagram explains the interconnectivity and peripherals on the development kit.

http://support.intrinsyc.com/account/register

for more details about
