Open-Q™ 820 (APQ8096) / 820Pro (APQ8096SG) µSOM Development Kit User Guide Version 1.4
• Supports all CSI interfaces
• All camera CSI connectors are on the carrier board edge
• Self-regulated camera modules can be powered with 3.3V power (MB_VREG_3P3)
• Uses JAE FI-RE41S-VF connector for exposing MIPI, CLK, GPIOs and Power rails.
• Please use JAE FI-RE41S-HF to mate with the camera connectors on the carrier
board
The figure above shows the three MIPI CAM0 (J5), CAM1 (J4) and CAM2 (J3) connectors.
The table below outlines the pin outs of these connectors
Table 3.8.20-1. MIPI CSI Camera Connector Pinouts (J5,J4,J3)
Pin#
CAM0 (J5)
1, 2,
MB_VREG_3P3
3
4
GND
5
VREG_L17A_2P8
6
MB_ELDO_CAM0_
DVDD
7, 8
VREG_L23A_2P8
9, 10
VREG_LVS1A_1P8
11
GND
12
FLASH_STROBE_
EN (APQ_GPIO22)
Figure 24 Camera Connectors (J5, J4, J3)
CAM1 (J4)
MB_VREG_3P3
GND
VREG_L18A_2P8
MB_ELDO_CAM1_D
VDD
MB_ELDO_CAM1_V
CM/
VREG_L23A_2P8
(DNP)
VREG_LVS1A_1P8
GND
FLASH_STROBE_E
N (DNP)
(APQ_GPIO22)
42
Copyright Intrinsyc Technologies Corporation
CAM2 (J3)
MB_VREG_3P3
GND
VREG_L29A_2P8
MB_ELDO_CAM2_D
VDD
VREG_L23A_2P8
VREG_LVS1A_1P8
GND
FLASH_STROBE_EN
(DNP) (APQ_GPIO22)
Description
Power output. Connected
to main +3.3V
MB_VREG_3P3 max
current 700mA
Ground
Power output. Connected
to PM8996 VREG_L17A/
L18A/ L29 regulator.
Default is +2.8V. Maximum
current 300mA
Power output. Connected
to U5, U6, and U71 AMS
LDO regulator. Default is
+1.2V. Maximum current
1A
Power output. Connected
to PM8996 VREG_L23A
regulator. Default is +2.8V.
Maximum current 300mA.
For CAM1 J4, U10 is used.
Default is 2.8V and
maximum current is 300mA
Power output. Connected
to PM8996 VREG_LVS1A
switch output. Default is
+1.8V. Maximum current
300mA
Ground
Output. Connected to
APQ8096 Default use is for
camera flash strobe enable
