Description
USB boot
NC
NC
NC
NC

3.8.24 Ethernet AVB Expansion Header J73

This header is used for interfacing with automotive peripherals via Ethernet AVB standard. Note that this is
used for Lantronix internal testing and is not supported.

3.8.25 VIP Expansion Header J71

This header is used for interfacing with Qualcomm legacy automotive VIP boards. Note that this is
for Lantronix internal testing and is not supported.
Open-Q™ 820 Dev Kit User Guide
Signal Pin
NO
FORCED_USB_BOO J26[11
T ]
NC J26[13
]
NC J26[15
]
NC J26[17
]
NC J26[19
]
Figure 25 J73 Ethernet AVB Expansion Header
Figure 26 J71 VIP Expansion Header
Description Signal
USB VBUS enable. USB_VBUS_DIS_N
Activating ESD protection
circuit when asserted low
NC NC
Chip reset input APQ_RESOUT_N
NC NC
GND GND
Open-Q™ 820 Development Kit
Pin
NO
J26[12
]
J26[14
]
J26[16
]
J26[18
]
J26[20
]
