3.8 Open-Q 820 / 820Pro µSOM Carrier Board
The Open-Q 820 / 820Pro µSOM Carrier board is a Mini-ITX form factor board with various
connectors used for connecting different peripherals. The following are the mechanical
properties of the carrier board:
Dimensions
Form Factor
Major Interfaces

3.8.1 Dip switch S10 Configuration Options

There is a DIP switch S10 on the top side of the Open-Q 820 / 820Pro µSOM carrier board.
The 8-bit switch allows the user to control the system configuration and boot options. Table
3.8-1 below outlines the pin outs and connections of this DIP switches.
Function
FORCED_USB_BOOT
NC
BOOT_CONFIG[3]
BOOT_CONFIG[2]
BOOT_CONFIG[1]
WATCHDOG
_DISABLE
N/C
GPS_ANT_SEL
Table 3.8-1 Dip Switch HW / SW configuration
DIP
Switch Description
S10-1 Toggles between FORCE USB boot
and EDL mode. Enables FORCE
USB (GPIO 57) when DIP switch
turned on
S10-2 N/A
S10-3 Enables APQ boot configuration 3
when DIP switch turned on.
Controlled by APQ GPIO104
See schematic for boot configuration
options.
NOTE: µSOMe boot configurations
are not supported on the
development kit.
S10-4 Enables APQ boot configuration 2
when DIP switch turned on.
Controlled by APQ-GPIO103
S10-5 Enables APQ boot configuration 1
when DIP switch turned on.
Controlled by APQ-GPIO 102
S10-6 Enables WATCHDOG_DISABLE
when DIP switch turned on.
Controlled by APQ-GPIO 101
S10-7 NA
S10-8 Option to select which antenna to
use for GPS. When DIP switch ON
GPS external antenna is being used
(SMA connector). When OFF, GPS
printed antenna is being used (on-
board)
